The Next Generation Unified Storage
Contact us for pricing!
Unity Combines Enterprise-Class Performance and Flexibility
Unity Unified Storage supports advanced block and file workloads and then adds the performance of all-flash configurations to meet the growing needs for mixed application workloads and virtualized environments.
Second Generation Unity
The new Unity systems offer up to 40% performance improvement over previous similar models, more flexible configurations, and cost reductions. New all-flash configurations are now available to meet the demands of customers’ high performance applications, as well as hybrid configurations for the more cost conscious.
Nexsan Unity supports Fibre Channel and iSCSI connectivity in addition to NAS protocols. HDD and SSD support can be tailored for the best mixed application deployment environment or all-flash configurations for high performance needs. The latest Intel® Xeon® E5 v4 Family Processor and increased memory allow for more IOPs, lower latency, and power to expand and deliver performance up to 40% over previous similarly configured systems. Additional ports, connectivity options, and the support of SMB 3.0 provides greater configuration flexibility.
Unity delivers on the performance you need in unified storage by blending solid state memory including DRAM and SSD to optimize block and file operations into a faulttolerant architecture. To make the most of your IT investment, Nexsan realigns the trade-off between performance, capacity, and costs with FASTier caching that accelerates I/O and provides high performance where it’s needed.
The Nexsan Unity all-flash, high performance arrays make it easy and affordable to meet the needs of critical business applications. All-flash configurations are supported on every Unity model with up to nine enclosures in the largest configurations so you can start small and scale as your requirements grow. With the advanced data reduction technologies, organizations can see an effective usable capacity of up to 3X the raw capacity. The configurations are optimized to get the most out of the flash SSDs while providing the performance at up to 500K IOPS to meet the most demanding applications.
Unity has three models, the UNITY6900, UNITY6900 and the Unity6900, so you can select the model that meets your current needs, but has the flexibility of expansion with a combination of drives and chassis. Unity capacity scales from 6TB up to 5.6PB and performance can be fine-tuned to your needs with FASTier or all-flash configurations.
Security and Compliance
Nexsan Unity has built in integration to offload data into the optional Unity Assureon Archive (UAA). With UAA you get tamper-proof storage to meet corporate and government regulatory requirements including HIPAA, SOX and SEC-17 as well as the additional protection you need from ransomware attacks. UAA enables IT administrators to centrally manage and enforce policies for each type of unstructured data in your organization. Once the policies are set, UAA manages and protects your unstructured data with its fully-automated processes for archiving, data integrity protection, multi-site replication and primary storage offload. Just set it and forget it. UAA also optimizes your backup infrastructure; so you can focus on protecting your structured data, servers and applications.
Primary Storage Offload Saves You Money
With modern workloads it’s possible that up to 80% of data stored is not accessed after one year. Unity with Unity Assureon Archive gives organizations the option to seamlessly offload Tier-1 data onto far less expensive archive storage. Unity with the addition of UAA has an integrated Archive Client which moves data into the archive, leaving shortcuts of the files on the Tier-1 Unity storage so users can easily access their information without ever knowing it was archived.
|Category||Feature||UNITY2200 (Entry Level)||UNITY4400 (Mid-Range)||UNITY6900 (High-End)|
|All-Flash Configuration||The all-flash configurations are optimized to get the most out of the flash SSDs while providing the performance to meet the most demanding applications. Performance up to 500K IOPS.|
|Supports Multiple Protocols||SAN Protocols (Fibre Channel, iSCSI), NAS Protocols (NFS, CIFS, SMB 1.0 to 3.0, FTP)|
|User Interface||Unity includes both a built-in HTML5-based UI and a comprehensive Command Line Interface (CLI). The Unity UI allows an administrator to easily manage and monitor a Unity deployment, regardless of size, from anywhere with just a web browser.|
|PCI Compliance||Unity supports TLS 1.2 for PCI compliance|
|Authentication||Active Directory, LDAP, and Local|
|Access||Windows, Mac, and Linux|
|Data Services||Advanced data reduction, thin provisioning with dead space reclamation, replication, and snapshots|
|Maximum Raw Capacity||336TB||2.23PB||5.66PB|
|System Memory (DRAM)||128GB||192GB||384GB|
|Write Cache Capacity||400GB SSDs||8GB NVDIMM||16GB NVDIMM|
|FASTier Read Cache Capacity||7.68TB||35TB||100TB|
|FASTier Read Cache||400GB | 800GB | 1.92TB | 3.84TB||800GB | 1.92TB | 3.84TB|
|7.2K RPM SAS HDDs (TB)||2 | 4 | 6 | 8 | 10 | 12 TB|
|10K RPM SAS HDDs||600GB | 900GB | 1.2TB | 1.8TB|
|SAS SSDs||800GB | 1.92TB | 3.84TB | 7.68TB|
|2.5” 10K SED Drives (GB)||N/A||600 | 900 | 1200 GB|
|3.5” 7.2K SED Drives (TB)||N/A||2 | 4 | 6 TB|
Download the UNITY Datasheet (PDF)
